Product Feature
1. Asynchronous motors are widely used in various sectors of the national economy. Direct starting of asynchronous motors poses issues such as low starting torque, high starting current, large impact on the power grid, difficulty in starting, significant impact on mechanical equipment, short motor lifespan, high maintenance workload, and high maintenance costs.
2. SSDHV high-voltage soft starters can reduce the voltage drop caused by direct motor starting, and the use of this product does not affect the normal operation of other devices on the grid. They can reduce the motor's inrush current, which can cause excessive localized temperature rise and reduce motor lifespan. Additionally, they can minimize the mechanical impact caused by direct starting, thus reducing wear on the driven machinery. They also decrease electromagnetic interference, as inrush currents can disrupt the normal operation of electrical instruments in the form of electromagnetic waves. High-voltage soft starters enable smooth starting and stopping, thereby improving operational efficiency.
3. The high-voltage soft starter unit includes the SSDHV-6 standard 6KV solid-state soft starter, the SSDHV-10 standard 10KV solid-state soft starte.
Product Selection
| Item No. | Votalge （kV） | Adaptable Motor (kW) | Current (A) | Dimensions（W*H*D） | |
| (-G) Single cabinet | (-E) All-in-one cabinet | ||||
| SSDHV- 420 - 6 | 6 | 420 | 50 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 630 - 6 | 6 | 630 | 75 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 800-6 | 6 | 800 | 96 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 1000 - 6 | 6 | 1000 | 120 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 1250 - 6 | 6 | 1250 | 150 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 1600 - 6 | 6 | 1600 | 200 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 1800 - 6 | 6 | 1800 | 218 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV-2250 - 6 | 6 | 2250 | 270 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 2500 - 6 | 6 | 2500 | 300 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 3300 - 6 | 6 | 3300 | 400 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 4150 - 6 | 6 | 415 | 500 | Custom model | Custom model |
| SSDHV- 5000 - 6 | 6 | 5000 | 600 | Custom model | Custom model |
| SSDHV- 420 -10 | 10 | 420 | 30 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 630 - 10 | 10 | 630 | 45 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 800 - 10 | 10 | 8000 | 60 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV-1000 - 10 | 10 | 1000 | 73 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 1250 - 10 | 10 | 1250 | 90 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 1600 - 10 | 10 | 1600 | 115 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 1800 - 10 | 10 | 1800 | 130 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 2250 - 10 | 10 | 2250 | 160 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 2500 - 10 | 10 | 2500 | 180 | 1000*2300*1500 | 1000*2300*1500 |
| SSDHV- 2800 - 10 | 10 | 2800 | 200 | 1000*2300*1500 | Custom model |
| SSDHV- 3300-10 | 10 | 3300 | 235 | 1000*2300*1500 | Custom model |
| SSDHV- 3500-10 | 10 | 3500 | 250 | 1000*2300*1500 | Custom model |
| SSDHV- 4000-10 | 10 | 4000 | 280 | 1000*2300*1500 | Custom model |
| SSDHV- 4500-10 | 10 | 4500 | 320 | 1000*2300*1500 | Custom model |
| SSDHV- 5500-10 | 10 | 5500 | 400 | 1000*2300*1500 | Custom model |
| SSDHV- 6000-10 | 10 | 6000 | 430 | 1000*2300*1500 | Custom model |
| SSDHV- 7000-10 | 10 | 7000 | 500 | 1000*2300*1500 | Custom model |
| SSDHV- 8500-10 | 10 | 8500 | 600 | 1000*2300*1500 | Custom model |
| SSDHV-10000-10 | 10 | 10000 | 720 | Custom model | Custom model |
| SSDHV-15000-10 | 10 | 15000 | 1080 | Custom model | Custom model |
Technical Parameter
| Item | Basic parameters |
| Load type | Three-phase high-voltage squirrel-cage asynchronous motor, synchronous motor |
| AC voltage | 6-10KVAC |
| Operating frequency | 50HZ/60Hz± 2Hz |
| Phase sequence | SSDHV allows operation under any phase sequence (can be set via parameters) |
| Bypass contactor | Contactor with direct start capability |
| Control power supply | AC220V ± 15% |
| Instantaneous overvoltage protection | dv/dt absorption network |
| Starting frequency | 1-6 times (per hour) |
| Environmental conditionsv | Ambient temperature: -20℃~+50℃ |
| Relative humidity: 5% ~ 95%, non-condensing | |
| Altitude less than 1500 meters (derating is required for altitudes above 1500 meters) | |
| Operating interface | |
| Language | Chinese, English |
| Data logging | |
| Fault recording | Record the latest 100 fault information |
| Protection function | |
| Phase failure protection | During startup or operation, any phase of the main power supply is disconnected |
| Running overcurrent protection | Setting of running overcurrent protection: 100~500%le |
| Phase current imbalance protection | Phase current imbalance protection: 20~ 100% |
| Overload protection | Overload protection level: 10A, 10, 20, 30 |
| Underload protection | Underload protection level: 50~ 100% |
| Underload protection action time: 0~ 10S | |
| Start timeout | Start time limit: 10~ 120S |
| Overvoltage protection | When the main power supply voltage is higher than 120% of the rated value, overvoltage protection |
| Under voltage protection | When the main power supply voltage is lower than 70% of the rated value, undervoltage protection |
| Phase sequence protection | Allows operation in any phase sequence (can be set via parameters) |
| Ground protection | Protection when the ground current is greater than the set value |
| Communication instructions | |
| Communication protocol/interface | Modbus RTU |
| Internet connection | Each SSDHV can communicate with 32 SSDHV devices via network |
| Function | Through the communication interface, you can observe the operating status and program |
| the meter shows | |
| mains voltage | Display three-phase mains voltage |
| Three phase current | Display three-phase main circuit current |
